Interface plug-in relay, 8 A, 2 CO, 230 V AC

Description Interface plug-in relay, 8 A, 2 CO, 230 V AC This Harmony RSB interfacing plug-in relay has a control coil voltage of 230V AC and has 2 changeover contacts double pole double throw with a rating of 8A. It helps to reduce the size of enclosures and increases machine reliability, you can mount nearly everywhere. Plug in type allows easy installation and maintenance. The product is IP40 and has a transparent cover allowing operator to visually inspect the status of contacts. Specifications Range of product: Harmony Electromechanical Relays Series name: RSB series Product or component type: Plug-in relay Relay type: Interface relay Contacts type and composition: 2 C/O status LED: Without [Uc] control circuit voltage: 230 V AC 50/60 Hz Control type: Without lockable test button [Ithe] conventional enclosed thermal current: 8 A at -40…40 °C Main Average resistance: 33000 Ohm network: AC at 20 °C /- 10 % [Ue] rated operational voltage: 184…345 V AC 50/60 Hz [Uimp] rated impulse withstand voltage: 3.6 kV conforming to IEC 61000-4-5 [Ie] rated operational current: 4 A (AC-1/DC-1) NC conforming to IEC8 A (AC-1/DC-1) NO conforming to IEC [Ui] rated insulation voltage: 400 V conforming to IEC 60947 Maximum switching voltage: 300 V DC conforming to IEC Drop-out voltage threshold: >= 0.15 Uc AC Load current: 8 A at 250 V AC8 A at 28 V DC minimum switching current: 10 mA Maximum switching capacity: 2000 VA/224 W minimum switching voltage: 12 V Minimum switching capacity: 120 mW at 10 mA, 12 V Operating time: 20 ms operating20 ms reset Mechanical durability: 5000000 cycles Electrical durability: 100000 cycles, 8 A at 250 V, AC-1 NO100000 cycles, 4 A at 250 V, AC-1 NC Safety reliability data: B10d = 100000 Operating rate: <= 600 cycles/hour under load<= 18000 cycles/hour no-load Average coil consumption: 0.75 VA AC Removable legend: Without Protection category: RT I Operating position: Any position Test levels: Level A group mounting Device presentation: Complete product Sale per indivisible quantity: 10 Contacts material: Silver alloy (AgNi) Shape of pin: Flat (PCB type) Product weight: 0.014 kg Compatibility code: RSB Complementary Dielectric strength: 1000 V AC between contacts2500 V AC between poles5000 V AC between coil and contact Vibration resistance: /- 1 mm (f= 10…55 Hz) conforming to IEC 60068-2-6 IP degree of protection: IP40 conforming to IEC 60529 Ambient air temperature for operation: -40…70 °C (AC) Standards: CSA C22.2 No 14UL 508IEC 61810-1 Product certifications: CSAEACUL Ambient air temperature for storage: -40…85 °C Shock resistance: 10 gn (duration = 11 ms) for not operating conforming to IEC 60068-2-275 gn (duration = 11 ms) for in operation conforming to IEC 60068-2-27 Packing Units Unit Type of Package 1: PCE Number of Units in Package 1: 1 Package 1 Height: 1.200 cm Package 1 Width: 2.000 cm Package 1 Length: 2.900 cm Package 1 Weight: 13.000 g Unit Type of Package 2: BB1 Number of Units in Package 2: 10 Package 2 Height: 1.700 cm Package 2 Width: 2.500 cm Package 2 Length: 31.100 cm Package 2 Weight: 146.000 g Unit Type of Package 3: S01 Number of Units in Package 3: 350 Package 3 Height: 15.000 cm Package 3 Width: 15.000 cm Package 3 Length: 40.000 cm Package 3 Weight: 5.240 kg Contractual warranty Warranty (in months): 18
